Silicone turbo air intake hose NEW HOLLAND TC56 (OEM 84057907) - VMQ+FVMQ inner

Silicone turbo air intake hose NEW HOLLAND TC56

Replacement hose between air filter and turbo inlet on the NEW HOLLAND TC56 combine. Specific construction to resist oil vapours from crankcase ventilation (blow-by) recycled into the intake.

Technical characteristics

• Outer material: red VMQ silicone
• Inner layer: FVMQ fluorosilicone (hydrocarbon resistant)
• Reinforcement: 3-ply polyester
• Wall thickness: 4 mm
• Temperature range: -50 °C to +200 °C
• Replaces OEM: 84057907

Application

• Machine: NEW HOLLAND TC56 combine harvester
• Circuit: turbo air intake (air filter → turbo)
• Specific: oil vapour contact via PCV gas recycling
• Sector: agricultural machinery

Technical advantages vs standard silicone

Standard VMQ silicone degrades on prolonged contact with oil vapours present in the air intake after crankcase blow-by recycling. The FVMQ inner layer ensures optimal chemical resistance to hydrocarbons, while the outer VMQ layer provides thermal resistance under the hood.

Packaging

1 silicone VMQ+FVMQ hose with clamps, in clear plastic bag.
