Silicone Cooling Hose New Holland TC56 – Reference 84057907

Product Definition and Technical Specifications

The REDOX silicone cooling hose for the New Holland TC56 is manufactured from high-grade VMQ silicone (polymethylvinylsiloxane) with 3-ply polyester reinforcement. Designed as a direct replacement for the original cooling hose on the New Holland TC56 combine harvester, it ensures reliable coolant circulation under the demanding conditions of intensive agricultural use.

Technical specifications:

• Material: 3-ply reinforced VMQ silicone with polyester braid
• Wall thickness: 4 mm
• Operating temperature: -50 °C to +180 °C (continuous)
• Operating pressure: 5 bar
• Compatible with all standard agricultural coolants (ethylene glycol, propylene glycol)
• Replaces OEM reference: 84057907

Application and Compatible Machine

This hose is specifically designed for the New Holland TC56 combine harvester, a 5-walker machine produced from approximately 1991 to 2007 in Belgium. Depending on the variant, the TC56 is fitted with either a Ford 6-cylinder diesel engine (approx. 155 hp) or a Genesis engine (approx. 170 hp). The TC56 remains a widely used cereal harvesting machine across European farms, valued for its robustness and straightforward maintenance.

OEM Reference

The REDOX hose is the direct replacement for the original part identified under New Holland manufacturer reference 84057907.

Permanent Stock and Fast Delivery

Harvest schedules leave no room for delays: a combine out of action during peak season represents a direct loss for any farming operation. REDOX keeps this hose in permanent stock to ensure immediate availability at any point in the year. Orders placed before 5 PM are dispatched the same day. Delivery is guaranteed within 24–48 hours throughout France and across Europe.
